For anyone wanting to connect an Eaton easyE4 control relay to serial Modbus RTU – for example to address frequency converters, energy meters or other Modbus-capable field devices – the base device is extended with the EASY-COM-RTU-M1. The communication module is mounted on the DIN rail to the left of the base device and coupled to it via the easyCOM connector. The module supports both operating modes: master/client (the easyE4 controls the field devices) and slave/server (the easyE4 is addressed by a higher-level system). This covers typical use cases from a decentralised stand-alone controller to integration with a SCADA system. 🏭 Typical applications Master mode – connect field devices: Frequency converters (e.g. Kinco KC100, INVT GD20), energy meters, sensors or actuators with Modbus RTU interface directly controlled and read out via the easyE4. Slave mode – pass data on: Integrate the easyE4 as a subordinate unit into an existing SCADA, control room or building management solution. Heterogeneous installations: Network devices from different manufacturers via a uniform protocol – without gateway effort. ⚙️ Prerequisites and compatibility Base device: Eaton easyE4 from hardware generation 05 (available from 04/2021) with firmware V1.40 or newer. Hardware generation 08 is fully compatible. Configuration: Via easySoft 8 – including Modbus mapping and diagnostics Engineering: Module firmware V1.01 (release notes MZ049016EN) brings stability and functional improvements ⚡ Key technical data Supply: 24 V DC (permissible 20.4 – 28.8 V), power consumption 1 W Connection to base device: easyCOM connector (mountable to the left) Connection to bus: Screw terminal RS-485 Protocol: Modbus RTU – configurable as either master (client) or slave (server) 🏷️ Manufacturer and standards The manufacturer is Eaton (Moeller series). The module is CE-certified and tested to UL Listed (file E205091), CSA, EN 50178, EN 61010, EN 61131-2 and EN 61000-6-2/-3. Additionally UL Hazardous Location Class I Division 2. 🔧 Mounting and scope of delivery DIN-rail mounting (35 mm per IEC/EN 60715), to the left of the easyE4 base device. Screw terminals for 0.2 – 4 mm² solid or 0.2 – 2.5 mm² flexible with ferrule. Dimensions: 36 × 90 × 58 mm (W × H × D), weight 0.1 kg, protection IP20. Recommended combination: Together with the EASY-E4-UC-12RC1 (HW V08) you get a complete Modbus-RTU-capable nano-PLC with display and Ethernet.

For anyone looking for a compact 24 V power supply for an Eaton easy series control relay – whether for the older easy500/700/800 or for an easyE4 base device – the EASY200-POW is a single-phase switched-mode power supply in a 2-SU DIN-rail housing. The units are primary-cycled and regulated, with SELV output per EN 60950 and radio interference class B per EN 55011/EN 55022. 🏭 Typical applications Powering small controls: easyE4 in the DC variant, easy500/700/800 or other DIN-rail devices that require up to 0.35 A at 24 V DC. Sensor supply: 24 V sensors, small actuators or auxiliary circuits in the control cabinet where a compact and particularly slim design (35.5 mm) is required. Redundant setups: Connect two units in parallel for higher availability or increased power – the outputs are approved for this. ⚡ Key technical data Input: 100 – 240 V AC, 50/60 Hz, single-phase Output: 24 V DC at 0.35 A (≈ 8.4 W) and 12 V DC at 0.02 A – both voltages available in parallel Protection: Overload protection with current limiting, continuous short-circuit proof LED indication: Green LED signals output voltage present Galvanic isolation: SELV (Safety Extra-Low Voltage) per EN 60950 🏷️ Manufacturer and standards The manufacturer is Eaton (Moeller series). The power supply is CE-certified and tested to UL, CSA, EN 50178, EN 55011, EN 55022 and EN 60950 (SELV). It is suitable for use in industrial as well as public low-voltage networks. 🔧 Mounting and scope of delivery DIN-rail mounting (35 mm per IEC/EN 60715). Screw terminals for 0.2 – 4 mm² solid or 0.2 – 2.5 mm² flexible with ferrule. Dimensions: 35.5 × 90 × 56.5 mm (W × H × D), weight 0.085 kg, protection IP20. Note on the product line: EASY200-POW originally belongs to the older easy500/easyPower family and is not part of the easyE4 hardware generation, but can be used as an external 24 V power supply for DC-fed easyE4 base devices. UC and AC variants of the easyE4 do not require an additional power supply.

📌 Hardware Generation 08 (production from 01/2023): Current hardware revision with firmware line V2.x. Fully cloud-ready, compatible with easyE RTD Advanced, all EASY-COM expansion modules and all current .e80 projects from easySoft 8. For anyone who needs a compact programmable controller for machines, equipment or building services – without the effort and cost of a full-scale PLC system – the Eaton EASY-E4-UC-12RC1 offers a complete nano-PLC with integrated display, Ethernet port and onboard Modbus TCP. The controller combines 8 digital inputs (4 of which can be switched to analog), 4 relay outputs up to 10 A AC and a real-time clock in a 4-SU housing. Programming is done on a PC with easySoft 8 in four languages (LD, FBD, ST, EDP) – or, when needed, directly on the device via the LCD display and keypad. 🏭 Typical applications Machine and equipment retrofit: Replace legacy relay logic in control cabinets with a flexible programmable solution – including Ethernet connectivity for remote access. Pump and fan control: Up to 4 high-speed counter inputs (10 kHz) for flow measurement or speed detection – including a real-time clock for time programs. Building automation: Coordinate lighting, heating, ventilation and air conditioning centrally. Pass data to higher-level systems via Modbus TCP. Energy management: Connect energy meters (e.g. Eaton EMD3P) and evaluate via the integrated data logging and cloud connectivity. 🖥️ Display and operation The monochrome LCD display with 128 × 96 pixels shows 6 lines of 16 characters – sufficient for status displays, simple operating menus and direct programming on the device via the eight buttons. The real-time clock runs at ± 5 s per day (≈ ± 0.5 h per year) and can be synchronised via the network. ⚡ Inputs and outputs in detail 8 digital inputs (I1 – I8): Input voltage 12 V DC, 24 V DC or 24 V AC. I1 – I4 additionally usable as high-speed counters up to 10 kHz, frequency counters up to 5 kHz or as incremental encoder input pairs (2 × 5 kHz, 90° offset). 4 analog inputs (I5 – I8): 0 – 10 V DC, 12-bit resolution, accuracy ± 2 %. With DC supply, switchable between digital and analog operation. 4 relay outputs: 8 A DC at 24 V (UL R 300) or 10 A AC at 240 V (UL B 300). Service life 10 million mechanical operations, 25,000 operations under typical load. 🔌 Power supply – Universal Current The UC variant accepts both DC and AC: 12 V DC (10.2 – 14.4 V), 24 V DC (20.4 – 28.8 V) or 24 V AC (20.4 – 26.4 V, 50/60 Hz). Reverse polarity protection included. Power consumption in operation: 3 W. 🌐 Communication and expansion Onboard: Ethernet (1 × RJ45, 10/100 Mbit/s) with TCP/IP and Modbus TCP. A microSD slot enables program backups, data logging and firmware updates without a PC. For serial bus systems, the device can be extended with the EASY-COM-RTU-M1 for Modbus RTU (master/client or slave/server). Up to 11 I/O expansion modules per base device – maximum 188 I/O points in full configuration. 💻 Programming with easySoft 8 The free demo version allows full engineering – only the final upload to the device requires the EASYSOFT-SWLIC license. Supported languages: LD (Ladder Diagram): Classic PLC logic per IEC 61131-3 FBD (Function Block Diagram): Graphical logic with function blocks ST (Structured Text): Similar to a high-level language, for complex calculations EDP (easy Device Programming): Eaton-specific, programmable directly on the device 🏷️ Manufacturer and reliability Eaton is one of the established industrial manufacturers in the European market – the easy family has been around since the late 1990s. The EASY-E4-UC-12RC1 is certified to CE, UL Listed (file E205091), cULus per UL 61010, CSA C22.2 No. 61010, EN 50178, EN 61010, EN 61131-2, EN 61000-6-2/-3 and DNV GL. It is additionally approved for UL Hazardous Location Class I Division 2, usable in groups A (acetylene), B (hydrogen), C (ethylene) and D (propane). 🔧 Mounting and scope of delivery DIN-rail mounting (35 mm per IEC/EN 60715) or wall mounting with bracket ZB4-101-GF1 (available separately). Screw terminals for cross-sections 0.2 – 4 mm² solid or 0.2 – 2.5 mm² flexible with ferrule, tightening torque 0.6 Nm. Dimensions: 72 × 90 × 58 mm (W × H × D), weight 0.25 kg, protection IP20. Scope of delivery: EASY-E4-UC-12RC1 control relay, operating instructions. Note: easySoft 8 license and patch cable to be ordered separately. For serial bus expansions an EASY-COM-RTU-M1 is recommended. ⚠️ Important notice on safety-related applications Eaton prohibits the use of the easyE4 for safety-relevant functions (personal or machine protection) and safety-related controls (burner, emergency stop, two-hand safety controls). Dedicated safety components are required for such functions.

The G2100E2 is a new 10" HMI touch panel from Kinco. It is a modern and versatile and very cost effective HMI touch panel with 10'' screen diagonal and a resolution of 1024 * 600 pixels from Kinco with Ethernet interface. The G2100E is a new series with high performance. It is compatible with the GL100E or the M2100E in terms of installation dimensions. The device is programmed with the new DTools Pro software.Compared to the GL100E, the G2100E has a faster processor, significantly more memory and greater viewing angle stability. This makes the user interface faster and smoother on the one hand and visually more attractive on the other.PLCs, frequency converters and other devices that you want to visualize or control can be connected via Ethernet and a serial interface. The touch panel offers you a versatile range of functions and simple graphical configuration of PLC communication. The touch panel is ideal for machine control systems or smaller system control elements. The device supports communication with over 60 PLC models, including Siemens S7-200, S7-1200, S7-300/400, S7-1500, Modbus RTU/TCP (master and slave), Allen Bradley, Thinget, Mitsubishi FX and many others. Further details can be found in the "PLC drivers" tab. Functions (excerpt): Versatile graphic elements for display and operation Animations Individual graphic elements and images possible Extensive data logging Recipe management VNC server and client for remote control (e.g. from smartphone or browser) PDF display on the HMI (new) User management and security Alarms and eventsSend messages by email via SMTP (encrypted) Own language switching for users programmable via text tables C macros for complex calculations Program and recipe download via USB, USB stick or Ethernet FTP server for retrieving CSVs and log files XY graphs with up to 64 characteristic curves possible, histograms Generation and display of QR codes Scheduler for calendar-controlled functions ... Note for new customers: You can test this device for 30 days without obligation. This device can of course also be ordered by existing customers at the price shown. How the test works for new customers: when you order this device for the first time, we offer you a 30-day right of return. As a first-time customer, you can return this device to us within 30 days. You only pay the invoice at the end of the test phase if you have decided to use the device. Order this device as normal; we will automatically send your first order as a test device. If you have any technical questions during the test, please write to us at support@spstiger.de. . Kinco HMIs are now being used by well over 100 of our customers in Germany. We are convinced that Kinco HMI touch panels also offer you as an automation specialist or machine and plant manufacturer a particularly cost-effective way of providing your customers with modern and versatile user interfaces.

Rokae CR7, SR5 und SR3 – Präzise Cobots für industrielle Automatisierung Die kollaborativen Roboter Rokae CR7, SR5 und SR3 bieten eine leistungsstarke Lösung für präzise und flexible Automatisierungsaufgaben. Mit Traglasten von 3 bis 7 kg und Reichweiten bis rund 900 mm eignen sie sich ideal für Montage, Maschinenbeschickung, Pick-&-Place oder Qualitätsprüfung. Durch integrierte Sicherheitsfunktionen können die Cobots direkt mit Menschen zusammenarbeiten und lassen sich schnell in bestehende Produktionsumgebungen integrieren. Typische Anwendungen Die Rokae Cobots werden besonders häufig eingesetzt für: Maschinenbeschickung von CNC- oder Spritzgussanlagen Montageprozesse in Elektronik oder Feinmechanik Pick-&-Place sowie Verpackungsaufgaben Automatisierte Qualitätsprüfung Damit eignen sie sich besonders für Branchen wie Automotive, Elektronikfertigung oder Metallverarbeitung. Modelle im Überblick CR7 – Leistungsstarker Allrounder Mit 7 kg Traglast eignet sich der CR7 besonders für Maschinenbeschickung, Montageaufgaben und Handling größerer Bauteile. SR5 – Kompakt und präzise Der SR5 ist für präzise Anwendungen in Elektronikfertigung, Qualitätsprüfung und Laborautomation optimiert. SR3 – Für leichte Präzisionsaufgaben Der SR3 eignet sich ideal für kleine Bauteile, Sortieraufgaben und präzise Montageprozesse.

Odot MG-CANEX - Making CANopen field devices accessible via Ethernet In many machines and systems, decentralized components communicate via CANopen networks (e.g. drives, encoders, IO modules). These serial fieldbus segments are difficult to use directly in modern Ethernet-based control systems because they lack a suitable network connection. The Odot MG-CANEX acts as a protocol converter here, converting CANopen data into Modbus TCP and thus enabling direct integration into Ethernet infrastructures. The MG-CANEX works as a master in the CANopen network and connects to standard CANopen slaves (PDO, SDO, Heartbeat). At the same time, it acts as a Modbus TCP server via which up to five TCP clients can access CANopen data in parallel. This makes it ideal when existing devices need to be accessible and readable via SCADA, MES, PLC Ethernet or IoT gateways - without expensive adaptations to the control software. Typical use cases: Retrofitting CANopen field devices in Ethernet networks Retrofit projects with gradual digitalization Integration of external units or machines into Ethernet-based monitoring systems Remote access to decentralized sensors/actuators via TCP/IP The MG-CANEX offers two Ethernet ports with switch function, galvanic isolation, DIN rail mounting and simple configuration via integrated software. This creates an economical, stable bridge between the CANopen field bus and modern Ethernet communication networks.

Odot ODOT-S7MPI V2.0 - Ethernet access to Siemens communication In many existing systems, Siemens controllers communicate via PPI, MPI or PROFIBUS interfaces, such as older S7-200/300/400 systems or CNC controllers. These serial protocols are difficult to use directly in modern IT/Ethernet environments, for example for production monitoring, MES connection or SCADA data access. The Odot ODOT-S7MPI V2.0 solves precisely this practical integration requirement by converting PPI/MPI/PROFIBUS communication into Ethernet protocols and thus bringing data directly into modern networks. The S7MPI can be connected directly to the communication port of the PLC without blocking additional programming ports. Data access for host systems, HMI clients or production management software is possible via S7 Ethernet or Modbus TCP without having to change existing PLC code. Typical applications: Access to PLC data via Ethernet for MES, SCADA or data logging Retrofit projects in which classic Siemens communication continues to be used Machine or line integration in modern IT infrastructures Simultaneous connection of several host clients (up to 32 connections) The ODOT-S7MPI V2.0 creates a practical, network-capable bridge between classic Siemens communication protocols and the Ethernet-based data world - a pragmatic way of integrating old PLC islands into modern automation environments without expensive conversions or PLC program changes.

Odot ODOT-S2/S4E2-4 - Bringing Modbus devices cleanly into the Ethernet Many automation systems use field devices with Modbus RTU or ASCII via serial interfaces (RS232/RS485). These tried-and-tested devices are often difficult to address directly in modern, Ethernet-based control and IT environments (e.g. SCADA, MES, IoT gateways) because the serial interface is not easily accessible to network devices. The Odot ODOT-S4E2-4 provides a remedy here: it converts serial Modbus RTU/ASCII communication into Modbus TCP and thus enables direct access to field devices via Ethernet networks - without additional software gateways or PLC code adaptations. The gateways can address several serial RS-485 buses and bring their participants into the network via two LAN ports. Typical application situations: Retrofitting serial Modbus sensors or counters in Ethernet-based SCADA/MES systems Retrofit projects with step-by-step modernization of the network infrastructure Remote access to field devices via TCP/IP networks Reduction of outdated serial connections in favor of standardized Ethernet communication The S4E2-4 works as a transparent protocol converter with a stable Modbus TCP connection, supports multiple simultaneous connections and can be configured via a web interface. It therefore offers a pragmatic, economical solution for integrating existing Modbus RTU/ASCII devices into modern automation and IT processes.

Odot ODOT-S1E1 V2.0 - Easily connect serial field devices to the Ethernet Many systems still contain serial devices with RS232/RS422/RS485 interfaces, such as older sensors, display devices or field modules. These are often difficult to integrate directly into modern Ethernet-based automation networks. The Odot ODOT-S1E1 V2.0 Serial Gateway provides a remedy here by seamlessly connecting serial interfaces with TCP/UDP Ethernet and thus enabling network-compatible integration. The S1E1 is particularly suitable when existing serial components are to be integrated into modern control environments (e.g. PLCs, servers, IoT gateways) or made accessible via Ethernet without expensive hardware conversions or complex protocol conversions. Typical applications: Networking old RS232/485/422 devices via Ethernet Retrofit projects with gradual digitization expansion Transferring serial data to TCP server/client or UDP networks Replacement or addition of fieldbus segments without complete network architecture conversion The gateway supports transparent data forwarding, both with and without protocol parsing (e.g. MODBUS RTU/ASCII), and can be configured via a web browser. It is designed for continuous industrial operation on 35 mm DIN rails and helps to economically transfer legacy devices to the Ethernet network.

Odot ODOT-PNM02 - Easily integrate field devices into PROFINET networks Many production plants consist of a mixture of older serial devices and modern control systems. Especially in retrofit projects or when gradually replacing components, the question arises: How can I integrate existing Modbus RTU/ASCII or proprietary serial devices into a PROFINET automation network without having to rebuild the entire communication? The Odot ODOT-PNM02 solves exactly this practical integration need. It converts serial protocols (Modbus-RTU/ASCII or non-standard protocols) into PROFINET communication and integrates existing devices directly into modern PROFINET control networks. Typical application scenarios: Retrofitting old field devices or measuring systems in PROFINET-based lines Integration of external units with a serial interface in modern automation architectures Retrofit projects in which serial devices are to continue to be used Reduction of engineering effort through direct PROFINET access to existing sensors/actuators The ODOT-PNM02 handles protocol conversion transparently, thus ensuring clear, structured data communication. Its galvanically isolated interfaces and robust design make it a pragmatic solution for cost-effective modernization and stable field integration.
