Solidot Profinet remote I/O module PN4 with 4 analog channels

Quantity	Unit price	Base price
To 3	€298.00*	€74.50* / 1 Channel
To 19	€283.10*	€70.78* / 1 Channel
To 39	€268.20*	€67.05* / 1 Channel
To 99	€253.30*	€63.33* / 1 Channel
From 100	€238.40*	€59.60* / 1 Channel

Prices excl. VAT plus shipping costs

Available, delivery time: 3 bis 5 Tage

Input and output variants

4 analog inputs (0 - 10 VDC)

4 analog inputs (4 - 20 mA)

4 analog outputs (0 - 10 VDC)

4 analog outputs (4 - 20 mA)

Modul

Product number:

SD.PN4.A04V

Manufacturer no.:

PN4-A04V

Create PDF quotation

Create PDF quotation for this product Hint: You can add multiple products to the cart and create a quotation in the cart. For logged in users the link will generate a quotation with their address.

Product information "Solidot Profinet remote I/O module PN4 with 4 analog channels"

Remote I/O as Profinet extension, ideal for integration into Profinet networks

With 4 analog channels

Electrical properties
Nominal supply voltage:	24 V DC
Permissible voltage range:	18 - 36 V DC
Digital I/O
Switch display:	Green LED
Analogue I/O
Analog inputs (number):	none
Analog outputs (designation & type):	- 5 to +5 V , - 10 to + 10 V , 0 - 10 V , 1 - 5 V , 16 bit
Analog outputs (number):	4
Interfaces, protocols and connections
Ethernet:	2 x 10/100 (RJ45)
Fieldbuses & protocols:	Profinet
Interfaces:	Ethernet
Terminal type:	Spring clamp
Dimensions and environmental properties
Assembly:	DIN rail
Cooling:	Ambient air (passive)
Dimensions (width x height x depth):	25 mm x 102 mm x 72 mm
Housing material:	Plastic
Moisture:	5 % - 95 % (non-condensing)
Operating temperature range:	0 °C to +55 °C
Protection class:	IP20
Storage temperature range:	- 20 °C to + 70 °C
Other properties
Model series:	PN4
Programming
Configurable via:	Profinet (GSD)
Certifications
CE certificate:	Yes

Manufacturer "Solidot"

Solidot was only founded in 2012 and is therefore still a relatively young company. It is now a leading manufacturer of remote I/O in Asia. The company specializes entirely in remote I/O and offers a wide variety of different bus couplers, form factors and assemblies.

Open manufacturer website
